Defiency Chart.

[NAKEDGARDENER]

Nothing special but might be useful to some.



[NAKEDGARDENER]

[TABLE="border: 1, cellpadding: 3, cellspacing: 0"]
[TR]
[h=3]Table 1. The 14 elements essential for plant growth and their mobility and role within the plant.[/h] [/TR]
[TR]
Macronutrients Symbol Mobile in plant Role in plant [/TR]
[TR]
[TD="colspan: 4"] Primary[/TD]
[/TR]
[TR]
[TD] Nitrogen[/TD]
[TD]N[/TD]
[TD]Yes[/TD]
[TD]Formation of amino acids, vitamins and proteins; cell division[/TD]
[/TR]
[TR]
[TD] Phosphorous[/TD]
[TD]P[/TD]
[TD]Yes[/TD]
[TD]Energy storage and transfer; cell growth; root and seed formation and growth; winter hardiness; water use[/TD]
[/TR]
[TR]
[TD] Potassium[/TD]
[TD]K[/TD]
[TD]Yes[/TD]
[TD]Carbohydrate metabolism, breakdown and translocation; water efficiency; fruit formation; winter hardiness; disease resistance[/TD]
[/TR]
[TR]
[TD="colspan: 4"] Secondary[/TD]
[/TR]
[TR]
[TD] Calcium[/TD]
[TD]Ca[/TD]
[TD]No[/TD]
[TD]Cell division and formation; nitrogen metabolism; translocation; fruit set[/TD]
[/TR]
[TR]
[TD] Magnesium[/TD]
[TD]Mg[/TD]
[TD]Yes[/TD]
[TD]Chlorophyll production; phosphorus mobility; iron utilization; fruit maturation[/TD]
[/TR]
[TR]
[TD] Sulfur[/TD]
[TD]S[/TD]
[TD]No[/TD]
[TD]Amino acids formation; enzyme and vitamin development; seed production; chlorophyll formation[/TD]
[/TR]
[TR]
[TD="colspan: 4"]Micronutrients[/TD]
[/TR]
[TR]
[TD] Boron[/TD]
[TD]B[/TD]
[TD]No[/TD]
[TD]Pollen grain germination and tube growth; seed and cell wall formation; maturity promotion; sugar translocation[/TD]
[/TR]
[TR]
[TD] Chlorine[/TD]
[TD]Cl[/TD]
[TD]Yes[/TD]
[TD]Role not well understood[/TD]
[/TR]
[TR]
[TD] Copper[/TD]
[TD]Cu[/TD]
[TD]No[/TD]
[TD]Metabolic catalyst; functions in photosynthesis and reproduction; increases sugar; intensifies color; improves flavor[/TD]
[/TR]
[TR]
[TD] Iron[/TD]
[TD]Fe[/TD]
[TD]No[/TD]
[TD]Chlorophyll formation; oxygen carrier; cell division and growth[/TD]
[/TR]
[TR]
[TD] Manganese[/TD]
[TD]Mn[/TD]
[TD]No[/TD]
[TD]Involved in enzyme systems; aids chlorophyll synthesis; P and CA availability[/TD]
[/TR]
[TR]
[TD] Molybdenum[/TD]
[TD]Mo[/TD]
[TD]Yes[/TD]
[TD]Nitrate reductase formation; converts inorganic phosphates to organic[/TD]
[/TR]
[TR]
[TD] Nickel[/TD]
[TD]Ni[/TD]
[TD]Yes[/TD]
[TD]Nitrogen metabolism and fixation; disease tolerance[/TD]
[/TR]
[TR]
[TD] Zinc[/TD]
[TD]Zn[/TD]
[TD]No[/TD]
[TD]Hormone and enzyme systems; chlorophyll production; carbohydrate, starch and seed formation[/TD]
[/TR]
[/TABLE]



[NAKEDGARDENER]

Once inside plants, nutrients are transported to where they are needed, typically to growing points. Once incorporated by the plant, some elements can be immobile while others can be remobilized. Immobile elements essentially get locked in place and that is where they stay. Those that can be remobilized can leave their original location and move to areas of greater demand. Knowing which are mobile or immobile is helpful in diagnosing deficiency symptoms.

Since immobile elements do not easily move within the plant, when deficiency symptoms occur they show up in new growth When mobile elements become limiting, they can be scavenged from older growth and moved to where they are most needed, causing deficiency symptoms in older growth

Nutriet deficiency Nutriet deficiency
Typical deficiency symptoms of a non- mobile nutrient (iron) within the plant. Note newer leaves are more affected. Typical deficiency symptoms of a mobile nutrient (nitrogen) within the plant. Note older leaves are senescing while younger leaves are still green.

Most nutrient deficiencies need a certain amount of time after growth begins for symptoms to occur. Early growth is often not fast enough or of a great enough volume for symptom expression. Deficiencies are often revealed when the plant is at maximum growth or at other times of high nutrient demand such as fruit development.

According to Michigan State University Extension, nutrient deficiencies can be due to a number of reasons. The most obvious is that the element is not in a high enough level naturally in the soil. Many sand-based soils with high leaching potential are often low in highly soluble nutrients. In some cases, the element is in adequate levels, but unavailable due to pH being too high or too low or the soil temperature being too low for adequate uptake. Other reasons could be too little or too much water or soil compaction. Remember all mineral elements need to come from the soil and if water uptake is interrupted for any reason, so is nutrient uptake.



[LurkingInTheGrass]

Thank you, tucking these into my tickle trunk for growing

I really like the element breakdown, what is the yes/no column? (Required by or provided by or something else?)



[NAKEDGARDENER]

Yes no column is denoting whether it is mobile or immobile in the plant.. thanks for pointing that out.



[9fingerleafs]

it must be mobility lurking
